Specifications
KEY FEATURES
| PRK3-EM | |
| Compatible Credential | 125khz, EM, PIN |
| Protocol, Interface | Wiegand 26-37 bits Led Line, Buzzer line |
| Operating Voltage | 12VDC to 14VDC |
| Tamper Alarm | Built-in rear light sensor & siren |
| Environmental | Operat. Temp: -40C to 60C Hum: 0% to 96 RH Portecttion: IP66 |
| Dimension | 122 mm(L) x 50mm(W) x 21mm(H) |
| Safety Standards | Designed to conform to UL 294 |
| FCC & IC Compliance | Complies with part 15 of the FCC rules Class A |
| PRK3-K | |
| Compatible Credential | 125khz, HID & EM, PIN |
| Protocol, Interface | Wiegand 26-37 bits Led Line, Buzzer line |
| Operating Voltage | 12VDC to 14VDC |
| Tamper Alarm | Built-in rear light sensor & siren |
| Environmental | Operat. Temp: -40C to 60C Hum: 0% to 96 RH Portecttion: IP66 |
| Dimension | 122 mm(L) x 50mm(W) x 21mm(H) |
| Safety Standards | Designed to conform to UL 294 |
| FCC & IC Compliance | Complies with part 15 of the FCC rules Class A |
| PRK3-KX | |
| Compatible Credential | 125khz, HID & EM – 13.56 mhz, Mifare, PIN |
| Protocol, Interface | Wiegand 26-37 bits Led Line, Buzzer line |
| Operating Voltage | 12VDC to 14VDC |
| Tamper Alarm | Built-in rear light sensor & siren |
| Environmental | Operat. Temp: -40C to 60C Hum: 0% to 96 RH Portecttion: IP66 |
| Dimension | 122 mm(L) x 50mm(W) x 21mm(H) |
| Safety Standards | Designed to conform to UL 294 |
| FCC & IC Compliance | Complies with part 15 of the FCC rules Class A |
RECOMMENDED WIRING
| MODELS | PRK3-KX, PRK3-K, PRK3-EM |
| WIRE TYPE | 6 x Conductors Shielded |
| SIZE | 22AWG to 22AWG |
| MAXIMUN LENGHT | 500 ft (150 m) |
